AEDR-8400-142
RoHS
/
Package 6-SMD Module
Category Sensors, Transducers / Optical Sensors - Reflective - Logic Output
Description
BROADCOM LIMITED AEDR-8400-142 REFLECTIVE OPT. ENCODER, 2CH, 318LPI
PDF
/
Inventory: 4721
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 6-SMD Module
Number of Pins 6
Technical
Packaging Tape & Reel (TR)
Published 2007
Feature Compact Model
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2A (4 Weeks)
Termination SMD/SMT
Max Operating Temperature 85°C
Min Operating Temperature -20°C
Voltage - Rated 5V
Voltage - Supply 2.6V~3V
Number of Functions 1
Current Rating 5mA
Output Voltage 7V
Operating Supply Voltage 2.8V
Number of Channels 2
Operating Supply Current 6mA
Optoelectronic Device Type LINEAR POSITION ENCODER
Max Output Voltage 3V
Sensing Distance 0.017 (0.43mm)
Sensing Method Reflective
Built in Switch No
Input Current 6mA
Nominal Supply Voltage (DC) 2.8V
Sensing Object Codewheel/Codestrip
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
