PT480
RoHS
/
Package Radial
Category Sensors, Transducers / Optical Sensors - Phototransistors
Description
SENSOR PHOTO 800NM SIDE VIEW RAD
PDF
/
Buying Options
Total Price: USD $0.44
Unit Price: USD $0.43795
≥1 USD $0.43795
≥10 USD $0.3591
≥100 USD $0.34865
≥500 USD $0.33725
≥1000 USD $0.32585
Inventory: 1171
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Technical
Light Current-Nom 1.7mA
Infrared Range YES
Dark Current 100μA
Wavelength 800nm
Collector Emitter Breakdown Voltage 35V
Max Collector Current 20mA
Collector Emitter Voltage (VCEO) 6V
Fall Time (Typ) 3.5 μs
Rise Time 3μs
Optoelectronic Device Type PHOTO TRANSISTOR
Viewing Angle 70°
Output Current 20mA
Power Dissipation 75mW
Configuration SINGLE
Polarity NPN
Number of Elements 1
Reach Compliance Code unknown
Number of Functions 1
Orientation Side View
Max Power Dissipation 75mW
Terminal Finish Tin/Lead (Sn/Pb)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e0
Published 1997
Packaging Tube
Operating Temperature -25°C~85°C TA
Physical
Shape ROUND
Number of Pins 2
Package / Case Radial
Mounting Type Through Hole
Mount Through Hole
