9874MN 006100
RoHS
/
Package /
Category Cables, Wires / Multiple Conductor Cables
Description
6 FSPR #20 PO FS PVC
PDF
/
Buying Options
Total Price: USD $5.55
Unit Price: USD $5.547003
≥1 USD $5.547003
Inventory: 4950
Minimum: 1
-
+
Technical Details
Compliance
Ratings UL Style 2937
Dimensions
Jacket (Insulation) Thickness 0.0160 0.406mm
Length 100.0' 30.5m
Technical
Shield Coverage 100%
Shield Type Foil
Conductor Insulation Polypropylene (PP)
Jacket (Insulation) Diameter 0.355 (9.02mm)
Usage Audio, Control, Instrumentation
Conductor Strand 26/34
Jacket Color Blue
Cable Type Multi-Pair
Connector Support Type WIRE AND CABLE
Voltage 300V
Wire Gauge 20 AWG
Number of Conductors 12 (6 Pair Twisted)
Reach Compliance Code compliant
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Drain Wire
Series SpaceMaker?
Packaging Spool
Operating Temperature -20°C~80°C
Physical
Shield Material Aluminum
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC)
Conductor Material Copper, Tinned
Supply Chain
Factory Lead Time 3 Weeks
