9554 0601000
RoHS
/
Package /
Category Cables, Wires / Multiple Conductor Cables
Description
CBL 4PR 18AWG SHLD
PDF
/
Inventory: 2909
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings UL Style 2464
Dimensions
Jacket (Insulation) Thickness 0.0530 1.346mm
Length 1000.0' 304.8m
Technical
Shield Coverage 100%
Shield Type Foil
Conductor Insulation Poly-Vinyl Chloride (PVC)
Jacket (Insulation) Diameter 0.466 (11.84mm)
Usage Instrumentation
Conductor Strand 19/30
Jacket Color Chrome
Cable Type Multi-Pair
Connector Support Type WIRE AND CABLE
Wire Gauge 18 AWG
Number of Conductors 8 (4 Pair)
Reach Compliance Code compliant
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Drain Wire, Rip Cord
Published 2012
Packaging Spool
Operating Temperature -30°C~105°C
Physical
Shield Material Aluminum
Jacket (Insulation) Material Poly-Vinyl Chloride (PVC)
Conductor Material Copper, Tinned
Supply Chain
Factory Lead Time 4 Weeks
