B78477P1008A24
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks With Magnetics
Description
Down B78477P ROHS3Compliant 2014 Modular Connector (Type) 0C~70C 15.0muin 0.38mum
PDF
/
Inventory: 4097
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Phosphor Bronze
Mounting Type Through Hole
Housing Material Thermoplastic
Shield Material Copper Alloy
Technical
Operating Temperature 0°C~70°C
Packaging Tray
Published 2014
Series B78477P
Feature Board Guide
Part Status Obsolete
Moisture Sensitivity Level (MSL) 2 (1 Year)
Termination Solder
Connector Type RJ45
Applications 10/100 Base-T, AutoMDIX
Number of Rows 1
Orientation 90° Angle (Right)
Shielding Shielded, EMI Finger
Contact Finish Gold
Number of Ports 2
LED Color Does Not Contain LED
Tab Direction Down
Number of Cores per Jack 4
Dimensions
Contact Finish Thickness 15.0μin 0.38μm
Height Above Board 0.541 13.75mm
Compliance
RoHS Status ROHS3 Compliant
