B78477P1004A314
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks With Magnetics
Description
Down B78477P ROHS3Compliant 2014 Modular Connector (Type) 0C~70C 15.0muin 0.38mum
PDF
/
Inventory: 9866
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height Above Board 0.541 13.75mm
Contact Finish Thickness 15.0μin 0.38μm
Technical
Number of Cores per Jack 4
Tab Direction Down
LED Color Green - Yellow
Number of Ports 1
Contact Finish Gold
Shielding Shielded, EMI Finger
Orientation 90° Angle (Right)
Number of Rows 1
Applications 10/100 Base-T, AutoMDIX
Connector Type RJ45
Termination Solder
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Feature Board Guide
Series B78477P
Published 2014
Packaging Tray
Operating Temperature 0°C~70°C
Physical
Shield Material Copper Alloy
Housing Material Thermoplastic
Mounting Type Through Hole
Contact Material Phosphor Bronze
