JXD0-0025NL image
Favorite
JXD0-0025NL image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks With Magnetics
Description CONN MAGJACK 1PORT 1000 BASE-T
PDF
/
Buying Options
Total Price: USD $7.54
Unit Price: USD $7.5416
≥1 USD $7.5416
≥10 USD $6.78568
≥100 USD $6.39232
≥500 USD $6.228464
≥1000 USD $6.064608
≥3000 USD $5.408973
Inventory: 551
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 19 Weeks

Physical

Contact Material Phosphor Bronze
Mounting Type Through Hole
Housing Material Thermoplastic
Shield Material Brass

Technical

Operating Temperature -40°C~85°C
Packaging Tray
Published 2017
Series PULSEJACK? JXD0
Feature Board Lock
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
Connector Type RJ45
Applications 10/100/1000 Base-T, AutoMDIX
Orientation 90° Angle (Right)
Shielding Shielded, EMI Finger
Contact Finish Gold
Number of Ports 1
LED Color Green - Yellow
Tab Direction Down
Number of Cores per Jack 8

Dimensions

Contact Finish Thickness 30.0μin 0.76μm
Height Above Board 0.537 13.65mm

Compliance

RoHS Status RoHS Compliant
