J0011D01BNL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks With Magnetics
Description
CONN MAGJACK 1PORT 100 BASE-TX
PDF
/
Buying Options
Total Price: USD $7.91
Unit Price: USD $7.9112
≥1 USD $7.9112
≥10 USD $7.1236
≥100 USD $6.71088
≥500 USD $6.53884
≥1000 USD $6.3668
≥3000 USD $5.678508
Inventory: 1104
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Height Above Board 0.545 13.84mm
Contact Finish Thickness 15.0μin 0.38μm
Length 16.26mm
Height 13.84mm
Technical
Number of Cores per Jack 4
Tab Direction Down
LED Color Green - Yellow
Number of Ports 1
Empty Shell NO
Contact Finish Gold
Shell Finish NICKEL
Current Rating 8mA
Number of Positions Loaded 8
Depth 21.59mm
Shielding Shielded
Orientation 90° Angle (Right)
Total Number of Contacts 8
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature YES
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Gender Female
Applications 10/100 Base-TX, AutoMDIX
Color Green, Yellow
Connector Type RJ45
ECCN Code EAR99
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Guide
JESD-609 Code e3
Series PULSEJACK? J0
Published 2006
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Manufacturer Package Identifier J0011D01BNL
Shield Material Brass
Housing Material Thermoplastic
Mounting Type Through Hole
Mount Through Hole
Contact Material Phosphor Bronze
Supply Chain
Factory Lead Time 9 Weeks
