5406528-1
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
CONN MOD JACK 8P8C R/A UNSHLD
PDF
/
Buying Options
Total Price: USD $3.39
Unit Price: USD $3.388
≥1 USD $3.388
≥10 USD $2.97176
≥100 USD $2.8941
≥500 USD $2.831814
≥1000 USD $2.739414
Inventory: 2422
Minimum: 1
-
+
Technical Details
Compliance
Ratings Cat5
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Length - Tail 2.54mm
Contact Finish Thickness - Mating 1.27μm
Contact Finish Thickness 50.0μin 1.27μm
Length 63.75mm
Height 12.83mm
Technical
Keyed No
Tab Direction Up
LED Color Does Not Contain LED
Number of Positions/Contacts 8p8c (RJ45, Ethernet)
Circuit Application Signal
Number of Ports 4
ELV Compliant
Number of Contacts 32
Contact Finish Gold
Current Rating 1.5A
Depth 15.24mm
Shielding Unshielded
Orientation 90° Angle (Right)
Pitch 2.04mm
Number of Rows 1
Color Black
Number of Positions 8
Connector Type Jack
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Guide
Published 2005
Packaging Tray
Operating Temperature -40°C~85°C
Physical
PCB Mounting Orientation Right Angle
Housing Material Thermoplastic
Mounting Type Through Hole
Contact Material Phosphor Bronze
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 25 Weeks
