95009-2641

Molex
RoHS
/
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description CONN MOD JACK 6P4C R/A UNSHLD
PDF
/
Inventory: 1365
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Supply Chain

Factory Lead Time 8 Weeks

Physical

Contact Material Brass, Bronze
Contact Plating Gold
Mount Through Hole
Material Polyester
Housing Material Thermoplastic

Technical

Published 2011
Part Status Discontinued
Termination Solder
ECCN Code EAR99
Connector Type TELECOM AND DATACOM CONNECTOR
Number of Positions 6
Max Operating Temperature 80°C
Min Operating Temperature -40°C
Color Black
Gender Female
Additional Feature STANDARD PROFILE,SNAP-FIT PEG
Subcategory Telecom and Datacom Connectors
Voltage - Rated DC 125V
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Orientation Right Angle
Shielding Unshielded
Current Rating 1.5A
Reference Standard UL
Reliability COMMERCIAL
Body Length or Diameter 0.587 inch
Number of Contacts 4
Mating Information MULTIPLE MATING PARTS AVAILABLE
Empty Shell NO
Contact Style TELCOM, MODULAR
Contact Resistance 20mOhm
Insulation Resistance 500MOhm
Body/Shell Style JACK
Max Voltage Rating (AC) 125V
Number of Ports 1
Direction Down
Hole Diameter 3.25 mm

Dimensions

Height 13.59mm
Width 16.38mm
Panel Thickness 1.6mm

Compliance

REACH SVHC Unknown
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
