43202-6104
RoHS
/
Package /
Category Connectors, Interconnects / Modular Connectors - Jacks
Description
CONN MOD JACK 6P4C R/A UNSHLD
PDF
/
Inventory: 954
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 13 Weeks
Physical
Contact Material Bronze
Contact Plating Gold
Mount Through Hole
Shell Material BRASS
Housing Material Nylon
Weight 2.21801g
Technical
Published 2011
Pbfree Code yes
Part Status Active
Number of Terminations 4
Termination Solder
ECCN Code EAR99
Connector Type TELECOM AND DATACOM CONNECTOR
Number of Positions 6
Max Operating Temperature 85°C
Min Operating Temperature -40°C
Color Black
Gender Female
Additional Feature LOW PROFILE
Subcategory Telecom and Datacom Connectors
Voltage - Rated DC 125V
Contact Finish - Mating NOT SPECIFIED
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Total Number of Contacts 6
Orientation Right Angle
Shielding Unshielded
Depth 18.03mm
Current Rating 1.5A
Shell Finish NICKEL
Reference Standard UL, CSA
Reliability COMMERCIAL
PCB Contact Pattern STAGGERED
Mating Information MULTIPLE MATING PARTS AVAILABLE
Empty Shell NO
Contact Style TELCOM, MODULAR
Contact Resistance 10mOhm
Insulation Resistance 500000000Ohm
Body/Shell Style JACK
Number of Ports 1
Durability 500 Cycles
Direction Down
Current Rating (Max) 1.5A
Dimensions
Height 11.58mm
Length 13.21mm
Plating Thickness 50μin
Compliance
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
