EA-21842-C36
RoHS
RoHS compliant
RoHS compliantPackage /
Category Audio Products / Microphones
Description
MICROPHONE COND ANALOG OMNI
PDF
/
Buying Options
Total Price: USD $20.96
Unit Price: USD $20.9616
≥1 USD $20.9616
≥10 USD $17.08872
≥100 USD $15.677024
≥500 USD $14.809696
Inventory: 721
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Shape Rectangular
Technical
Packaging Bulk
Published 2006
Series EA
Size / Dimension 0.219Lx0.157W 5.56mmx3.99mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder Pads
Type Electret Condenser
Resistance 3.5kOhm
Voltage - Rated 1.3V
Depth 2.26mm
Current Rating 50μA
Frequency 4.8kHz
Output Type Analog
Max Supply Voltage 10V
Min Supply Voltage 900mV
Operating Supply Current 50μA
Impedance 3.5kOhm
Direction Omnidirectional
Frequency Range 100Hz~4.8kHz
Sensitivity -59dB ±3dB @ 74dB SPL
Port Location Side
Dimensions
Height 2.26mm
Compliance
REACH SVHC No SVHC
RoHS Status RoHS Compliant
