BXTM-26747-D53
RoHS
RoHS compliant
RoHS compliantPackage /
Category Audio Products / Microphones
Description
MICROPHONE COND ANALOG OMNI
PDF
/
Buying Options
Total Price: USD $65.6
Unit Price: USD $65.600361
≥1 USD $65.600361
≥200 USD $25.387547
≥500 USD $24.494775
≥1000 USD $24.053641
Inventory: 7000
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Dimensions
Height 1.7mm
Technical
Port Location Top
Sensitivity -55.5dB ±3dB @ 74dB SPL
Frequency Range 100Hz~9.5kHz
Direction Omnidirectional
Impedance 5.25kOhm
Operating Supply Current 75μA
Output Type Analog
Voltage - Rated 1.1V
Type Electret Condenser
Termination Solder Pads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Size / Dimension 0.141Lx0.141W 3.57mmx3.57mm
Series BXTM
Packaging Tray
Physical
Shape Square
Supply Chain
Factory Lead Time 4 Weeks
