SST39VF200A-70-4I-MAQE
RoHS
RoHS compliant
RoHS compliantPackage 48-WFBGA
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount SST39VF200A Tray ic memory 70ns 6mm 30mA 2Mb
PDF
/
Buying Options
Total Price: USD $1.41
Unit Price: USD $1.408
≥1 USD $1.408
Inventory: 761
Minimum: 1
-
+
Technical Details
Technical
Number of Sectors/Size 64
Sector Size 2K
Common Flash Interface YES
Command User Interface YES
Toggle Bit YES
Data Polling YES
Programming Voltage 2.7V
Word Size 16b
Sync/Async Asynchronous
Standby Current-Max 0.00002A
Density 2 Mb
Address Bus Width 17b
Write Cycle Time - Word, Page 20μs
Memory Width 16
Organization 128KX16
Data Bus Width 16b
Memory Interface Parallel
Memory Format FLASH
Access Time 70ns
Memory Type Non-Volatile
Nominal Supply Current 30mA
Memory Size 2Mb 128K x 16
Supply Voltage-Min (Vsup) 2.7V
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Pin Count 48
Base Part Number SST39VF200A
Terminal Pitch 0.5mm
Supply Voltage 3V
Number of Functions 1
Terminal Position BOTTOM
Voltage - Supply 2.7V~3.6V
Technology CMOS
HTS Code 8542.32.00.51
ECCN Code EAR99
Number of Terminations 48
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series SST39 MPF?
Published 2000
Packaging Tray
Operating Temperature -40°C~85°C TA
Dimensions
Height Seated (Max) 0.73mm
Length 6mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Physical
Number of Pins 48
Package / Case 48-WFBGA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 5 Weeks
