SST25PF080B-80-4C-QAE
RoHS
RoHS compliant
RoHS compliantPackage 8-WDFN Exposed Pad
Category Integrated Circuits (ICs) / Memory
Description
e3 Surface Mount SST25PF080B Tube ic memory 80MHz 12ns 5mm 12mA
PDF
/
Inventory: 1609
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-WDFN Exposed Pad
Number of Pins 8
Weight 10.886217mg
Technical
Operating Temperature 0°C~70°C TA
Packaging Tube
Published 2012
Series SST25
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 8
Terminal Finish Matte Tin (Sn)
Technology CMOS
Voltage - Supply 2.3V~3.6V
Terminal Position DUAL
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Terminal Pitch 1.27mm
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number SST25PF080B
Supply Voltage-Max (Vsup) 3.6V
Supply Voltage-Min (Vsup) 2.3V
Interface SPI, Serial
Memory Size 8Mb 1M x 8
Nominal Supply Current 30mA
Memory Type Non-Volatile
Operating Mode SYNCHRONOUS
Max Supply Current 12mA
Clock Frequency 80MHz
Access Time 12 ns
Memory Format FLASH
Memory Interface SPI
Data Bus Width 8b
Write Cycle Time - Word, Page 10μs
Screening Level TS 16949
Programming Voltage 3V
Dimensions
Height 800μm
Length 6mm
Width 5mm
Compliance
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
