93LC66AX-E/SN
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount 93LC66A Tube ic memory 2MHz 250ns 3.9mm 2mA
PDF
/
Inventory: 1646
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3.9mm
Length 4.9mm
Height Seated (Max) 1.75mm
Technical
Write Protection SOFTWARE
Data Retention Time-Min 200
Write Cycle Time-Max (tWC) 6ms
Endurance 1000000 Write/Erase Cycles
Serial Bus Type MICROWIRE
Standby Current-Max 0.000005A
Density 4 kb
Write Cycle Time - Word, Page 6ms
Memory Width 8
Memory Interface SPI
Memory Format EEPROM
Access Time 250 ns
Clock Frequency 2MHz
Memory Type Non-Volatile
Nominal Supply Current 2mA
Memory Size 4Kb 512 x 8
Interface Serial
Supply Voltage-Min (Vsup) 2.5V
Power Supplies 3/5V
Supply Voltage-Max (Vsup) 5.5V
Pin Count 8
Base Part Number 93LC66A
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.27mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 2.5V~5.5V
Technology CMOS
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 1998
Packaging Tube
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 8
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 6 Weeks
