24LC04BH-I/MS
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount 24LC04BH Tube ic memory 400kHz 900ns 3mm 3mA
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.259324
≥1 USD $0.259324
≥10 USD $0.210261
≥30 USD $0.189229
≥100 USD $0.162996
≥500 USD $0.151312
≥1000 USD $0.144301
Inventory: 5679
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3mm
Length 3mm
Height Seated (Max) 1.1mm
Technical
Reverse Pinout NO
I2C Control Byte 1010XXMR
Page Size 16words
Data Polling YES
Write Protection HARDWARE
Data Retention Time-Min 200
Write Cycle Time-Max (tWC) 5 ms
Endurance 1000000 Write/Erase Cycles
Serial Bus Type I2C
Screening Level ISO/TS-16949
Standby Current-Max 0.000005A
Density 4 kb
Write Cycle Time - Word, Page 5ms
Memory Width 8
Output Characteristics OPEN-DRAIN
Memory Interface I2C
Memory Format EEPROM
Access Time 900ns
Clock Frequency 400kHz
Memory Type Non-Volatile
Nominal Supply Current 3mA
Memory Size 4Kb 256 x 8 x 2
Interface I2C, Serial
Operating Supply Voltage 5V
Pin Count 8
Base Part Number 24LC04BH
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 2.5V~5.5V
Technology CMOS
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2007
Packaging Tube
Operating Temperature -40°C~85°C TA
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Tin
Supply Chain
Factory Lead Time 5 Weeks
