24AA025T-I/ST
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Memory
Description
EAR99 Surface Mount 24AA025 Tape & Reel (TR) ic memory 400kHz 900ns 3mm 3mA
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.256475
≥1 USD $0.256475
≥10 USD $0.206821
≥30 USD $0.185552
≥100 USD $0.159005
≥500 USD $0.147176
≥1000 USD $0.140086
Inventory: 7140
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 8 Weeks
Physical
Contact Plating Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2002
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Technology CMOS
Voltage - Supply 1.7V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 2.5V
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 24AA025
Pin Count 8
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 2/5V
Supply Voltage-Min (Vsup) 1.7V
Interface I2C, Serial
Memory Size 2Kb 256 x 8
Nominal Supply Current 3mA
Memory Type Non-Volatile
Clock Frequency 400kHz
Access Time 900ns
Memory Format EEPROM
Memory Interface I2C
Memory Width 8
Write Cycle Time - Word, Page 5ms
Density 2 kb
Standby Current-Max 0.000001A
Serial Bus Type I2C
Endurance 1000000 Write/Erase Cycles
Write Cycle Time-Max (tWC) 5 ms
Data Retention Time-Min 200
I2C Control Byte 1010DDDR
Dimensions
Height Seated (Max) 1.2mm
Length 4.4mm
Width 3mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
