23LC512-E/ST
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Memory
Description
e3 Surface Mount 23LC512 Tube ic memory 16MHz 3mm 512Kb 64K x 8 2.5V
PDF
/
Buying Options
Total Price: USD $1.12
Unit Price: USD $1.123842
≥1 USD $1.123842
≥10 USD $0.949227
≥30 USD $0.854698
≥100 USD $0.74704
≥500 USD $0.698463
≥1000 USD $0.677456
Inventory: 9769
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 4.4mm
Height Seated (Max) 1.2mm
Technical
Parallel/Serial SERIAL
Screening Level TS 16949
Memory Width 8
Memory Interface SPI - Quad I/O
Memory Format SRAM
Clock Frequency 16MHz
Operating Mode SYNCHRONOUS
Memory Type Volatile
Memory Size 512Kb 64K x 8
Supply Voltage-Min (Vsup) 2.5V
Supply Voltage-Max (Vsup) 5.5V
Base Part Number 23LC512
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position DUAL
Voltage - Supply 2.5V~5.5V
Technology CMOS
Terminal Finish Matte Tin (Sn) - annealed
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Published 2012
Packaging Tube
Operating Temperature -40°C~125°C TA
Physical
Number of Pins 8
Surface Mount YES
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 20 Weeks
