23LC1024T-I/ST
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Memory
Description
e3 Surface Mount 23LC1024 Tape & Reel (TR) ic memory 20MHz 25ns 4.4mm 10mA
PDF
/
Buying Options
Total Price: USD $3.6
Unit Price: USD $3.59983
≥1 USD $3.59983
≥10 USD $3.39606
≥100 USD $3.20383
≥500 USD $3.02248
≥1000 USD $2.8514
≥3000 USD $2.69
Inventory: 3724
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 5 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-TSSOP (0.173, 4.40mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Published 2012
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Terminal Finish Matte Tin (Sn) - annealed
Technology CMOS
Voltage - Supply 2.5V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 0.65mm
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 23LC1024
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 5.5V
Power Supplies 3/5V
Interface SPI, Serial
Memory Size 1Mb 128K x 8
Number of Ports 2
Nominal Supply Current 10mA
Memory Type Volatile
Clock Frequency 20MHz
Access Time 25 ns
Memory Format SRAM
Memory Interface SPI - Quad I/O
Output Characteristics 3-STATE
Memory Width 8
Address Bus Width 24b
Density 1 Mb
I/O Type COMMON/SEPARATE
Sync/Async Synchronous
Word Size 8b
Output Enable NO
Reverse Pinout NO
Dimensions
Length 4.4mm
Compliance
RoHS Status ROHS3 Compliant
