DS1216F
RoHS
/
Package 32-DIP (0.600, 15.24mm) Socket
Category Integrated Circuits (ICs) / Memory - Controllers
Description
DS1216 2011 Tube EAR99 memory controller 15.24mm 4.5V~5.5V 0C~70C
PDF
/
Buying Options
Total Price: USD $3.49
Unit Price: USD $3.485498
≥1 USD $3.485498
≥10 USD $3.288207
≥100 USD $3.102082
≥500 USD $2.926491
≥1000 USD $2.760849
Inventory: 7463
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case 32-DIP (0.600, 15.24mm) Socket
Surface Mount NO
Number of Pins 32
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Published 2011
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 32
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Additional Feature 10 YEARS DATA RETENTION; SERIAL 64-BIT PROTOCOL; ACCURACY 1 MIN/MONTH @ 25 DEGREE C
HTS Code 8473.30.11.40
Subcategory Timer or RTC
Technology CMOS
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 240
Supply Voltage 5V
Terminal Pitch 2.54mm
Base Part Number DS1216
Pin Count 32
Operating Supply Voltage 5V
Memory Type ROM
Logic Function Clock
Time Format HH:MM:SS:hh
Time-Min 1/100SECOND
Interrupt Capability N
Volatile NO
Information Access Method SERIAL, FIXED PROTOCOL
Controller Type Smartwatch ROM
Dimensions
Height Seated (Max) 11.94mm
Length 40.635mm
Width 15.24mm
Compliance
Radiation Hardening No
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
