1612618-4
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
CONN SKT SODIMM 200POS R/A SMD
PDF
/
Buying Options
Total Price: USD $7
Unit Price: USD $7.0048
≥1 USD $7.0048
≥10 USD $6.1072
≥100 USD $5.94638
≥500 USD $5.785674
≥1000 USD $5.43209
≥3000 USD $5.399944
Inventory: 1157
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Stack Height 9.1948mm
Contact Finish Thickness Flash
Length 75.9mm
Height 9.82mm
Technical
Circuit Application Power
Contact Current Rating 500mA
Sealable No
Memory Type DDR2 SDRAM
Connector Style SODIMM
Polarization Key POLARIZED HOUSING
Max Current Rating 500mA
ELV Compliant
Row Spacing 6.1976 mm
Insulation Resistance 50000000Ohm
Contact Style BELLOWED TYPE
Rated Current (Signal) 0.5A
Housing Color Black
UL Flammability Code 94V-0
Contact Gender FEMALE
Body Breadth 0.37 inch
PCB Contact Pattern RECTANGULAR
Number Of PCB Rows 2
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Current Rating 500mA
Depth 26.5mm
Orientation Right Angle
Total Number of Contacts 200
Pitch 600μm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Voltage - Rated 25V
Number of Rows 2
Min Operating Temperature -55°C
Max Operating Temperature 85°C
Number of Positions 200
Connector Type Socket
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Guide, Latches
Published 2007
Packaging Tray
Physical
Housing Material Thermoplastic
Number of Pins 1
Mounting Feature Normal, Standard - Top
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 day ago)
Factory Lead Time 25 Weeks
