6-390114-1
RoHS
/
Package /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
Memory Card Connectors SKT,SODIMM,144P,SDRAM3.3V,LOW,
PDF
/
Buying Options
Total Price: USD $13.51
Unit Price: USD $13.507226
≥1 USD $13.507226
≥10 USD $12.742664
≥100 USD $12.021381
≥500 USD $11.34092
≥1000 USD $10.698984
Inventory: 9227
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Stack Height 3.9878mm
Plating Thickness 10μin
Length 69.9mm
Technical
Circuit Application Signal
Memory Type SDRAM
Dielectric Withstanding Voltage 1000VAC V
Polarization Key POLARIZED HOUSING
ELV Compliant
Body/Shell Style SOCKET
Insulation Resistance 250MOhm
Contact Style BELLOWED TYPE
Housing Color Natural
UL Flammability Code 94V-0
Body Breadth 0.157 inch
PCB Contact Pattern RECTANGULAR
Number of Contacts 144
Number Of PCB Rows 2
Row Spacing - Mating 6.1976 mm
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Depth 29.9mm
Orientation Right Angle
Pitch 800μm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Additional Feature LATCHED, POLARIZED
Gender Female
Number of Rows 2
Min Operating Temperature -67°C
Max Operating Temperature 221°C
Connector Type CARD EDGE CONNECTOR
ECCN Code EAR99
Termination Solder
Pbfree Code yes
Packaging Tape and Reel
Physical
Housing Material Plastic
Mount Surface Mount
Contact Plating Gold
