14-56-2252
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Free Hanging, Panel Mount
Description
Headers & Wire Housings CGrid SL IDT Opt G 15 SAu 25Ckt
PDF
/
Buying Options
Total Price: USD $7.01
Unit Price: USD $7.008459
≥1 USD $7.008459
≥10 USD $6.611757
≥100 USD $6.237506
≥500 USD $5.88444
≥1000 USD $5.551355
Inventory: 7193
Minimum: 1
-
+
Technical Details
Physical
Contact Material Bronze
Contact Plating Gold
Mount Cable, Free Hanging
Housing Material Polyester
Technical
JESD-609 Code e4
Pbfree Code yes
Termination IDT
ECCN Code EAR99
Connector Type IDC, Receptacle, Socket
Number of Positions 25
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Black
Number of Rows 1
Voltage - Rated 250V
Additional Feature STACKABLE
HTS Code 8536.69.40.40
Fastening Type Latch
Subcategory Headers and Edge Type Connectors
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Pitch 2.54mm
Total Number of Contacts 25
Orientation Straight
Current Rating 3A
Reference Standard UL
Reliability COMMERCIAL
Mating Information MULTIPLE MATING PARTS AVAILABLE
Contact Gender Female
UL Flammability Code 94V-0
Body Depth 0.6 inch
Contact Style SQ PIN-SKT
Contact Resistance 15mOhm
Body/Shell Style PLUG
Polarization Key POLARIZED HOUSING
Wire/Cable Type Discrete
Wire/Cable Gauge 24 AWG
Max Voltage Rating (DC) 250.25kV
Contact Pattern RECTANGULAR
Insertion Force-Max 2.224 N
Glow Wire Compliant Non-compliant
Dimensions
Height 15.2mm
Length 63.5mm
Width 2.51mm
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
