1717468-3
RoHS
/
Package /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
SEMI-HARD TRAY DDR SODIMM SOCK
PDF
/
Buying Options
Total Price: USD $7.04
Unit Price: USD $7.04
≥1 USD $7.04
≥10 USD $6.13228
≥100 USD $5.9708
≥500 USD $5.80954
≥1000 USD $5.45446
≥3000 USD $5.422199
Inventory: 698
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Stack Height 6.5mm
Length 71.5mm
Height 6.5mm
Technical
Current Rating (Max) 500mA
Contact Rating (Current) 500mA
Circuit Application Power
Sealable No
Memory Type DDR SDRAM
Housing Color Black
UL Flammability Code 94V-0
Contact Gender FEMALE
Number of Contacts 200
Row Spacing - Mating 6.1976 mm
Depth 26.5mm
Orientation Right Angle
Pitch 600μm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Voltage - Rated 2.5V
Number of Rows 2
Min Operating Temperature -67°C
Max Operating Temperature 185°C
Connector Type Socket
Termination SMD/SMT, Solder
Pbfree Code yes
Physical
Housing Material Thermoplastic
Mount Surface Mount
Contact Plating Gold
Contact Material Copper
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
