10124632-0241103LF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
MO-309 RoHS Compliant COMMERCIAL UL DIMM Socket 0.57inch
PDF
/
Inventory: 4296
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 9 Weeks
Physical
Contact Material COPPER ALLOY
Mount Through Hole
Mounting Type Through Hole
Mounting Feature Normal, Standard - Top
Technical
Packaging Tray
Published 2015
JESD-609 Code e3
Feature Board Lock, Latches
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Solder
ECCN Code EAR99
Number of Positions 288
Number of Rows 2
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Pitch 850μm
Total Number of Contacts 288
Orientation Straight
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold
Reliability COMMERCIAL
Body Length or Diameter 5.591 inch
Number Of PCB Rows 4
PCB Contact Pattern STAGGERED
Body Depth 0.57 inch
Contact Style BELLOWED TYPE
Connector Style DIMM
Memory Type DDR4 SDRAM
Insulator Color BLACK
Standards MO-309
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 30μin
Length - Termination 0.083 inch
Compliance
RoHS Status RoHS Compliant
