10124632-0231601LF
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
MO-309 RoHS Compliant COMMERCIAL UL DIMM Socket 0.157inch
PDF
/
Inventory: 4159
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Dimensions
Length - Termination 0.094 inch
Plating Thickness 15μin
Contact Finish Thickness 15.0μin 0.38μm
Compliance
RoHS Status RoHS Compliant
Technical
Standards MO-309
Insulator Color BLACK
Memory Type DDR4 SDRAM
Connector Style DIMM
Termination Type SOLDER
Mating Contact Pitch 0.033 inch
Contact Style BELLOWED TYPE
Body Depth 0.57 inch
Body Breadth 0.157 inch
PCB Contact Pattern STAGGERED
Number Of PCB Rows 4
Body Length or Diameter 5.591 inch
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Number of Conductors ONE
Terminal Pitch 1.7018mm
Total Number of Contacts 288
Subcategory Headers and Edge Type Connectors
HTS Code 8536.69.40.40
Number of Rows 2
Number of Positions 288
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Lock, Latches
JESD-609 Code e3
Packaging Tray
Physical
Mounting Feature Normal, Standard - Top
Mounting Type Through Hole
Mount Through Hole
Contact Material COPPER ALLOY
Supply Chain
Factory Lead Time 9 Weeks
