10120194-001LF
RoHS
/
Package /
Category Connectors, Interconnects / Memory Connectors - Inline Module Sockets
Description
MO-269 RoHS Compliant COMMERCIAL UL RDIMM Socket 30mOhm 85C 0.5A 700VAC V
PDF
/
Inventory: 6867
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material COPPER ALLOY
Contact Plating GXT, Gold
Mount Through Hole
Mounting Type Through Hole
Mounting Feature Normal, Standard - Top
Technical
Packaging Tray
Published 2012
JESD-609 Code e3
Feature Board Guide, Latches
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Press-Fit
ECCN Code EAR99
Number of Positions 240
Number of Rows 2
HTS Code 8536.69.40.40
Subcategory Headers and Edge Type Connectors
Pitch 2mm
Total Number of Contacts 240
Orientation Straight
Number of Conductors ONE
Reference Standard UL
Contact Finish Gold, GXT?
Reliability COMMERCIAL
Body Length or Diameter 5.866 inch
Number Of PCB Rows 4
PCB Contact Pattern STAGGERED
Operating Temperature (Max) 85°C
Operating Temperature (Min) -55°C
Body Depth 0.846 inch
Rated Current (Signal) 0.5A
Contact Style BELLOWED TYPE
Contact Resistance 30mOhm
Insulation Resistance 1000000Ohm
Body/Shell Style RECEPTACLE
Polarization Key POLARIZED KEY
Dielectric Withstanding Voltage 700VAC V
Connector Style RDIMM
Memory Type DDR3 SDRAM
PCB Contact Row Spacing 0.075 mm
Insulator Color BLACK
Standards MO-269
Dimensions
Contact Finish Thickness 30.0μin 0.76μm
Plating Thickness 30μin
Compliance
RoHS Status RoHS Compliant
