SN74SSTV16857DGVR
RoHS
RoHS compliant
RoHS compliantPackage 48-TFSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Specialty Logic
Description
IC REG BUFFER 14-BIT 48-TVSOP
PDF
/
Buying Options
Total Price: USD $3.33
Unit Price: USD $3.32595
≥1 USD $3.32595
≥10 USD $2.72935
≥100 USD $2.64385
≥500 USD $2.55835
≥1000 USD $2.4738
Inventory: 1129
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 48-TFSOP (0.173, 4.40mm Width)
Number of Pins 48
Weight 120.003531mg
Technical
Operating Temperature 0°C~70°C
Packaging Cut Tape (CT)
Series 74SSTV
JESD-609 Code e4
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 48
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Other Logic ICs
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 2.3V~2.7V
Terminal Pitch 0.4mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 74SSTV16857
Pin Count 48
Qualification Status Not Qualified
Polarity Non-Inverting
Power Supplies 2.5V
Number of Circuits 1
Max Supply Voltage 2.7V
Min Supply Voltage 2.3V
Number of Bits 14
Propagation Delay 2.8 ns
Logic Function Buffer
Output Characteristics 3-STATE
Logic Type Registered Buffer with SSTL_2 Compatible I/O for DDR
Max Frequency 200MHz
Trigger Type POSITIVE EDGE
High Level Output Current -20mA
Low Level Output Current 20mA
Dimensions
Length 9.7mm
Width 4.4mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
