SN74ABT18504PMRG4
RoHS
RoHS compliant
RoHS compliantPackage 64-LQFP
Category Integrated Circuits (ICs) / Logic - Specialty Logic
Description
IC SCAN TEST DEVICE 20BIT 64LQFP
PDF
/
Inventory: 7949
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 64-LQFP
Number of Pins 64
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Series 74ABT
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 64
Additional Feature WITH INDEPENDENT OUTPUT ENABLE FOR EACH DIRECTION; WITH CLOCK ENABLE
HTS Code 8542.39.00.01
Subcategory Bus Driver/Transceivers
Packing Method TAPE AND REEL
Technology BICMOS
Terminal Position QUAD
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 4.5V~5.5V
Terminal Pitch 0.5mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 74ABT18504
Pin Count 64
Qualification Status Not Qualified
Operating Supply Voltage 5.5V
Power Supplies 5V
Number of Ports 2
Number of Bits 20
Family ABT
Output Characteristics 3-STATE
Logic Type Scan Test Device with Universal Bus Transceivers
Output Polarity TRUE
Prop. Delay@Nom-Sup 6.5 ns
Propagation Delay (tpd) 6.8 ns
Control Type INDEPENDENT CONTROL
Power Supply Current-Max (ICC) 40mA
Count Direction BIDIRECTIONAL
Translation N/A
Dimensions
Height Seated (Max) 1.6mm
Length 10mm
Width 10mm
Compliance
RoHS Status ROHS3 Compliant
