MC10EP17DW
RoHS
/
Package 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Specialty Logic
Description
IC RCVR/DRVR QUAD ECL DFF 20SOIC
PDF
/
Buying Options
Total Price: USD $7.33
Unit Price: USD $7.332808
≥1 USD $7.332808
≥10 USD $6.917753
≥100 USD $6.526174
≥500 USD $6.15677
≥1000 USD $5.808272
Inventory: 1432
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295, 7.50mm Width)
Number of Pins 20
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2008
Series 10EP
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
ECCN Code EAR99
Additional Feature CAN ALSO OPERATE WITH -3V TO -5.5V SUPPLY IN NECL MODE
Subcategory Line Driver or Receivers
Technology ECL
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 4
Supply Voltage 3V~5.5V
Terminal Pitch 1.27mm
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number 10EP17
Pin Count 20
Qualification Status Not Qualified
Operating Supply Voltage 5.5V
Power Supplies +-3.3/+-5V
Nominal Supply Current 68mA
Number of Bits 4
Logic Function AND, Receiver
Data Rate 3 Tbps
Logic Type Differential Receiver/Driver
Differential Output YES
Interface IC Type LINE TRANSCEIVER
Interface Standard GENERAL PURPOSE
Receive Delay-Max 0.3 ns
Transmit Delay-Max 0.3 ns
Dimensions
Height Seated (Max) 2.65mm
Length 12.8mm
Width 7.5mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
