MC100EP16TDTG
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Logic - Specialty Logic
Description
IC RCVR/DRVR ECL DIFF 5V 8TSSOP
PDF
/
Buying Options
Total Price: USD $9.39
Unit Price: USD $9.3896
≥1 USD $9.3896
≥10 USD $8.63104
≥100 USD $8.273408
Inventory: 87
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 3.1mm
Length 3.1mm
Height 950μm
Technical
Number of Receivers 1
Transmit Delay-Max 0.3 ns
Negative Supply Voltage-Nom -4.5V
Receive Delay-Max 0.3 ns
Interface Standard GENERAL PURPOSE
Driver Number of Bits 1
Interface IC Type LINE TRANSCEIVER
Differential Output YES
Logic Type Differential Receiver/Driver
Halogen Free Halogen Free
Max Input Voltage 2.415V
Logic Function AND, Receiver
Propagation Delay 350 ps
Nominal Supply Current 39mA
Min Supply Voltage 3V
Max Supply Voltage 5.5V
Power Supplies -4.5V
Pin Count 8
Base Part Number 100EP16
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Supply Voltage 3V~5.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology ECL
Subcategory Line Driver or Receivers
Additional Feature CAN ALSO OPERATE WITH -3V TO -5.5V SUPPLY IN NECL MODE
Terminal Finish Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series 100EP
Published 2000
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
Factory Lead Time 4 Weeks
