SN74F299DWR
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
F/FAST 74F299 ROHS3Compliant Tape & Reel (TR) shift register 11ns 95mA 500.000539mg 70000000Hz
PDF
/
Buying Options
Total Price: USD $0.67
Unit Price: USD $0.67165
≥1 USD $0.67165
≥10 USD $0.551
≥100 USD $0.5339
≥500 USD $0.5168
≥1000 USD $0.4997
Inventory: 1131
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 20-SOIC (0.295, 7.50mm Width)
Number of Pins 20
Weight 500.000539mg
Technical
Operating Temperature 0°C~70°C
Packaging Tape & Reel (TR)
Series 74F
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 20
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Additional Feature HOLD MODE; COMMON I/O PINS; TOTEMPOLE SERIAL SHIFT RIGHT & SHIFT LEFT OUTPUTS; GATED OUTPUT CONTROL
Packing Method TR
Technology TTL
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number 74F299
Function Universal
Qualification Status Not Qualified
Output Type Tri-State
Operating Supply Voltage 5V
Number of Elements 1
Power Supplies 5V
Load Capacitance 50pF
Propagation Delay 11 ns
Turn On Delay Time 15 ns
Family F/FAST
Logic Function Shift Register
Direction Bidirectional
Output Characteristics 3-STATE
Logic Type Shift Register
Output Polarity TRUE
Max I(ol) 0.024 A
Number of Bits per Element 8
Trigger Type POSITIVE EDGE
Schmitt Trigger No
Power Supply Current-Max (ICC) 95mA
Number of Input Lines 10
fmax-Min 70 MHz
Max Frequency@Nom-Sup 70000000Hz
Dimensions
Height 2.65mm
Length 12.8mm
Width 7.5mm
Thickness 2.35mm
Compliance
RoHS Status ROHS3 Compliant
Lead Free Lead Free
