MC14538BDTR2
RoHS
/
Package 16-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Multivibrators
Description
e4 4538 Not Qualified 2008 multivibrator 3V~18V 5mm 8.8mA 8.8mA 95ns
PDF
/
Inventory: 3312
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 4.4mm
Length 5mm
Technical
Number of Data/Clock Inputs 2
Schmitt Trigger Input Yes
Independent Circuits 2
Output Polarity COMPLEMENTARY
Logic Type Monostable
Current - Output High, Low 8.8mA 8.8mA
Logic Function Multivibrator
Family 4000/14000/40000
Turn On Delay Time 600 ns
Quiescent Current 700μA
Propagation Delay 95ns
Supply Voltage-Min (Vsup) 3V
Power Supplies 5/15V
Supply Voltage-Max (Vsup) 18V
Operating Supply Voltage 12V
Qualification Status Not Qualified
Pin Count 16
Base Part Number 4538
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 2
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~18V
Technology CMOS
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Series 4000B
Published 2008
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Number of Pins 16
Package / Case 16-TSSOP (0.173, 4.40mm Width)
Mounting Type Surface Mount
Mount Surface Mount
