8409501FA
RoHS
/
Package /
Category Integrated Circuits (ICs) / Logic - Shift Registers
Description
COMPLEMENTARY Contains Lead DUAL POSITIVE EDGE shift register 50pF 125C 2V 21000000Hz
PDF
/
Inventory: 4735
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Physical
Surface Mount YES
Number of Pins 16
Technical
Number of Terminations 16
Max Operating Temperature 125°C
Min Operating Temperature -55°C
Additional Feature SISO OPERATION ALSO AVAILABLE
Packing Method TUBE
Technology CMOS
Terminal Position DUAL
Terminal Form FLAT
Peak Reflow Temperature (Cel) NOT SPECIFIED
Number of Functions 1
Supply Voltage 5V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 16
Qualification Status Qualified
Operating Supply Voltage 5V
Supply Voltage-Max (Vsup) 6V
Power Supplies 2/6V
Temperature Grade MILITARY
Supply Voltage-Min (Vsup) 2V
Load Capacitance 50pF
Number of Bits 8
Family HC/UH
Logic Function Shift Register
Direction Unidirectional
Output Polarity COMPLEMENTARY
Logic IC Type PARALLEL IN SERIAL OUT
Max I(ol) 0.0052 A
Trigger Type POSITIVE EDGE
Propagation Delay (tpd) 225 ns
Schmitt Trigger No
fmax-Min 25 MHz
Max Frequency@Nom-Sup 21000000Hz
Dimensions
Height 2.03mm
Length 10.3mm
Width 6.73mm
Thickness 1.65mm
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
