SN74HC259DG4

Texas Instruments
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Logic - Latches
Description SOIC HC/UH ACTIVE (Last Updated: 1week ago) D-Type latch circuit 6V 5.2mA 250ns 141.690917mg
PDF
/
Buying Options
Total Price: USD $0.21
Unit Price: USD $0.206664
≥1 USD $0.206664
≥200 USD $0.079981
≥500 USD $0.077172
≥1000 USD $0.075781
Inventory: 1212
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No

Dimensions

Thickness 1.58mm
Width 3.91mm
Length 9.9mm
Height 1.75mm

Technical

Number of Output Lines 8
Schmitt Trigger No
Low Level Output Current 5.2mA
High Level Output Current -5.2mA
Trigger Type LOW LEVEL
Max I(ol) 0.0052 A
Logic IC Type D LATCH
Logic Function D-Type
Family HC/UH
Turn On Delay Time 13 ns
Propagation Delay 250 ns
Number of Bits 8
Current - Output 5.2mA
Load Capacitance 50pF
Min Supply Voltage 2V
Max Supply Voltage 6V
Temperature Grade INDUSTRIAL
Polarity Non-Inverting
Number of Elements 1
Operating Supply Voltage 5V
Pin Count 16
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology CMOS
Packing Method TUBE
Subcategory FF/Latches
Min Operating Temperature -40°C
Max Operating Temperature 85°C
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 1
Pbfree Code yes
JESD-609 Code e4

Physical

Weight 141.690917mg
Number of Pins 16
Package / Case SOIC
Mount Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 1 week ago)
