SN74ACT533DWR
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Latches
Description
Surface Mount ROHS3Compliant Obsolete CMOS D-Type Transparent Latch 50pF -40C~85C 2.65mm 10.5ns
PDF
/
Buying Options
Total Price: USD $10
Unit Price: USD $9.997042
≥1 USD $9.997042
≥10 USD $9.43117
≥100 USD $8.89733
≥500 USD $8.393707
≥1000 USD $7.918592
Inventory: 4420
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Height Seated (Max) 2.65mm
Technical
Independent Circuits 1
Number of Input Lines 8
Max I(ol) 0.024 A
Logic Type D-Type Transparent Latch
Current - Output High, Low 24mA 24mA
Output Characteristics 3-STATE
Logic Function D-Type, Latch
Family ACT
Turn On Delay Time 2.5 ns
Propagation Delay 10.5 ns
Number of Bits 8
Number of Ports 2
Load Capacitance 50pF
Power Supplies 5V
Polarity Inverting
Circuit 8:8
Operating Supply Voltage 5V
Output Type Tri-State
Qualification Status Not Qualified
Pin Count 20
Base Part Number 74ACT533
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Packing Method TAPE AND REEL
Subcategory Bus Driver/Transceiver
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Series 74ACT
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 20
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount
