SN74LVC32AMPWREPG4
RoHS
RoHS compliant
RoHS compliantPackage 14-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
Lead Free OR Gate TTL Surface Mount OR Gate Inverter IC 50pF -55C~125C 3.6V 24mA 24mA
PDF
/
Buying Options
Total Price: USD $7.42
Unit Price: USD $7.418381
≥1 USD $7.418381
≥10 USD $6.998472
≥100 USD $6.602328
≥500 USD $6.22861
≥1000 USD $5.876052
Inventory: 1124
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-TSSOP (0.173, 4.40mm Width)
Number of Pins 14
Weight 57.209338mg
Technical
Operating Temperature -55°C~125°C
Packaging Tape & Reel (TR)
Series 74LVC
JESD-609 Code e4
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Subcategory Gates
Packing Method TR
Technology CMOS
Voltage - Supply 2V~3.6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 2.7V
Base Part Number 74LVC32
Pin Count 14
Number of Outputs 1
Output Type TTL
Number of Elements 4
Supply Voltage-Max (Vsup) 3.6V
Power Supplies 3.3V
Supply Voltage-Min (Vsup) 2V
Load Capacitance 50pF
Propagation Delay 3.8 ns
Quiescent Current 10μA
Family LVC/LCX/Z
Logic Function OR
Number of Inputs 2
Current - Output High, Low 24mA 24mA
Logic Type OR Gate
Max Propagation Delay @ V, Max CL 3.8ns @ 3.3V, 50pF
Schmitt Trigger NO
Logic Level - Low 0.8V
Logic Level - High 2V
Dimensions
Height 1.2mm
Length 5mm
Width 4.4mm
Thickness 1mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
