CD74HCT10MT
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
NAND 74HCT10 EAR99 74HCT logic gate circuit 24ns @ 4.5V 50pF 1.75mm 4mA 4mA 2V
PDF
/
Buying Options
Total Price: USD $1.12
Unit Price: USD $1.1176
≥1 USD $1.1176
≥10 USD $0.99616
≥100 USD $0.945824
≥500 USD $0.776776
Inventory: 808
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 8.65mm
Height 1.75mm
Technical
Logic Level - High 2V
Logic Level - Low 0.8V
Schmitt Trigger NO
Max Propagation Delay @ V, Max CL 24ns @ 4.5V, 50pF
Max I(ol) 0.004 A
Logic Type NAND Gate
Current - Output High, Low 4mA 4mA
Logic Function NAND
Family HCT
Quiescent Current 2μA
Propagation Delay 24 ns
Output Current 4mA
Load Capacitance 50pF
Power Supplies 5V
Number of Elements 3
Operating Supply Voltage 5V
Max Output Current 4mA
Qualification Status Not Qualified
Number of Outputs 1
Pin Count 14
Base Part Number 74HCT10
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Number of Functions 3
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Packing Method TR
Subcategory Gates
ECCN Code EAR99
Termination SMD/SMT
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74HCT
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C
Physical
Weight 129.387224mg
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 6 Weeks
