CD74HCT27E
RoHS
/
Package 14-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
NOR Gate Through Hole Non-RoHS Compliant COMMERCIAL NOR Gate Inverter IC -55C~125C 5.5V 4mA 4mA 23ns @ 4.5V 50pF
PDF
/
Buying Options
Total Price: USD $0.56
Unit Price: USD $0.5632
≥1 USD $0.5632
≥10 USD $0.4928
≥100 USD $0.46288
≥500 USD $0.377784
≥1000 USD $0.350909
≥3000 USD $0.298654
Inventory: 1327
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Current - Quiescent (Max) 2μA
Logic Level - High 2V
Logic Level - Low 0.8V
Max Propagation Delay @ V, Max CL 23ns @ 4.5V, 50pF
Logic Type NOR Gate
Current - Output High, Low 4mA 4mA
Number of Inputs 3
Family HCT
Number of Circuits 3
Supply Voltage-Min (Vsup) 4.5V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status COMMERCIAL
JESD-30 Code R-PDIP-T14
Supply Voltage 5V
Number of Functions 3
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Number of Terminations 14
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Series 74HCT
Packaging Tube
Operating Temperature -55°C~125°C
Physical
Surface Mount NO
Package / Case 14-DIP (0.300, 7.62mm)
Mounting Type Through Hole
