MC74AC10D
RoHS
/
Package 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
NAND 74AC10 e0 74AC logic gate circuit 7ns @ 5V 50pF 8.65mm 24mA 24mA 6V
PDF
/
Buying Options
Total Price: USD $0.28
Unit Price: USD $0.27645
≥1 USD $0.27645
≥10 USD $0.22705
≥100 USD $0.2204
≥500 USD $0.2128
≥1000 USD $0.20615
Inventory: 1104
Minimum: 1
-
+
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Number of Pins 14
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2006
Series 74AC
JESD-609 Code e0
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
Terminal Finish Tin/Lead (Sn/Pb)
Subcategory Gates
Technology CMOS
Voltage - Supply 2V~6V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 240
Number of Functions 3
Supply Voltage 5V
Reach Compliance Code not_compliant
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number 74AC10
Pin Count 14
Number of Outputs 1
Qualification Status Not Qualified
Operating Supply Voltage 5V
Supply Voltage-Max (Vsup) 6V
Supply Voltage-Min (Vsup) 2V
Load Capacitance 50pF
Propagation Delay 7 ns
Quiescent Current 4μA
Turn On Delay Time 8 ns
Family AC
Logic Function NAND
Current - Output High, Low 24mA 24mA
Logic Type NAND Gate
Number of Gates 3
Max Propagation Delay @ V, Max CL 7ns @ 5V, 50pF
Schmitt Trigger NO
Logic Level - Low 0.9V ~ 1.65V
Logic Level - High 2.1V ~ 3.85V
Dimensions
Length 8.65mm
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
