MC74AC02NG
RoHS
/
Package 14-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
Lead Free NOR Gate Through Hole RoHS Compliant NOR Gate Inverter IC 50pF -40C~85C 6V 24mA 24mA
PDF
/
Buying Options
Total Price: USD $3.6
Unit Price: USD $3.596774
≥1 USD $3.596774
≥10 USD $3.393187
≥100 USD $3.201117
≥500 USD $3.019926
≥1000 USD $2.848984
Inventory: 1099
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case 14-DIP (0.300, 7.62mm)
Number of Pins 14
Weight 4.535924g
Technical
Operating Temperature -40°C~85°C
Packaging Tube
Published 2006
Series 74AC
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
Terminal Finish Tin (Sn)
Subcategory Gates
Technology CMOS
Voltage - Supply 2V~6V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 74AC02
Pin Count 14
Number of Outputs 1
Operating Supply Voltage 5V
Supply Voltage-Max (Vsup) 6V
Supply Voltage-Min (Vsup) 2V
Load Capacitance 50pF
Output Current 24mA
Propagation Delay 6.5 ns
Quiescent Current 4μA
Turn On Delay Time 7.5 ns
Family AC
Logic Function NOR
Number of Inputs 2
Current - Output High, Low 24mA 24mA
Logic Type NOR Gate
Number of Gates 4
Max Propagation Delay @ V, Max CL 6.5ns @ 5V, 50pF
Prop. Delay@Nom-Sup 8 ns
Schmitt Trigger NO
Logic Level - Low 0.9V ~ 1.65V
Logic Level - High 2.1V ~ 3.85V
Dimensions
Height 6.35mm
Length 6.35mm
Width 25.4mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status RoHS Compliant
Lead Free Lead Free
