74AC00PC
RoHS
/
Package 14-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Gates and Inverters
Description
Lead Free NAND Gate Through Hole RoHS Compliant NAND Gate Inverter IC -40C~85C 2.1V-3.85V 24mA 24mA 1.62g
PDF
/
Buying Options
Total Price: USD $0.83
Unit Price: USD $0.8303
≥1 USD $0.8303
≥10 USD $0.68115
≥100 USD $0.66025
≥500 USD $0.6384
≥1000 USD $0.6175
Inventory: 1159
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC Unknown
Radiation Hardening No
Technical
Logic Level - High 2.1V ~ 3.85V
Logic Level - Low 0.9V ~ 1.65V
Max Propagation Delay @ V, Max CL 8ns @ 5V, 50pF
Number of Gates 4
Logic Type NAND Gate
Current - Output High, Low 24mA 24mA
Number of Inputs 2
Logic Function NAND
Turn On Delay Time 9.5 ns
Quiescent Current 2μA
Propagation Delay 10 ns
Output Current 24mA
Number of Outputs 1
Base Part Number 74AC00
Voltage - Supply 2V~6V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series 74AC
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Weight 1.62g
Number of Pins 14
Package / Case 14-DIP (0.300, 7.62mm)
Mounting Type Through Hole
Mount Through Hole
