SN74AUC1G79DCKRG4
RoHS
RoHS compliant
RoHS compliantPackage 5-TSSOP, SC-70-5, SOT-353
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Lead Free Not Qualified Standard D-Type Flip Flop -40C~85C TA 10muA 2.5pF 0.8V~2.7V
PDF
/
Buying Options
Total Price: USD $0.27
Unit Price: USD $0.26885
≥1 USD $0.26885
≥10 USD $0.2204
≥100 USD $0.21375
≥500 USD $0.2071
≥1000 USD $0.20045
Inventory: 3104
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Thickness 900μm
Width 1.25mm
Length 2mm
Height 1.1mm
Technical
Max Frequency@Nom-Sup 200000000Hz
Clock Edge Trigger Type Positive Edge
Input Capacitance 2.5pF
Trigger Type Positive Edge
Prop. Delay@Nom-Sup 3.9 ns
Max Propagation Delay @ V, Max CL 1.8ns @ 2.5V, 30pF
Max I(ol) 0.009 A
Current - Output High, Low 9mA 9mA
Output Characteristics 3-STATE
Current - Quiescent (Iq) 10μA
Logic Function D-Type, Flip-Flop
Family AUC
Turn On Delay Time 5 ns
Propagation Delay 2.4 ns
Clock Frequency 275MHz
Number of Bits 1
Output Current 9mA
Number of Circuits 1
Supply Voltage-Min (Vsup) 0.8V
Supply Voltage-Max (Vsup) 2.7V
Polarity Non-Inverting
Output Type Non-Inverted
Qualification Status Not Qualified
Function Standard
Base Part Number 74AUC1G79
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 1.2V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 0.8V~2.7V
Technology CMOS
Packing Method TR
Subcategory FF/Latches
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type D-Type
ECCN Code EAR99
Number of Terminations 5
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74AUC
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA
Physical
Weight 2.494758mg
Number of Pins 5
Package / Case 5-TSSOP, SC-70-5, SOT-353
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 6 Weeks
