CD74HC73MT
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Tape & Reel (TR) 74HC73 e4 74HC flip flop 8.65mm 2V 28ns @ 6V 50pF 60MHz
PDF
/
Buying Options
Total Price: USD $1.14
Unit Price: USD $1.144
≥1 USD $1.144
≥10 USD $1.02256
≥100 USD $0.970464
Inventory: 143
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Dimensions
Thickness 1.58mm
Width 3.91mm
Length 8.65mm
Height 1.75mm
Technical
Clock Edge Trigger Type Negative Edge
Power Supply Current-Max (ICC) 0.04mA
Schmitt Trigger No
Input Capacitance 10pF
Trigger Type Negative Edge
Prop. Delay@Nom-Sup 40 ns
Max Propagation Delay @ V, Max CL 28ns @ 6V, 50pF
Number of Bits per Element 1
Max I(ol) 0.006 A
Current - Output High, Low 5.2mA 5.2mA
Logic Function Flip-Flop, JK-Type
Family HC/UH
Turn On Delay Time 13 ns
Quiescent Current 4μA
Propagation Delay 160 ns
Clock Frequency 60MHz
Output Current 5.2mA
Load Capacitance 50pF
Number of Circuits 2
Supply Voltage-Min (Vsup) 2V
Supply Voltage-Max (Vsup) 6V
Polarity Non-Inverting
Output Type Differential
Qualification Status Not Qualified
Function Reset
Base Part Number 74HC73
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 4.5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2V~6V
Technology CMOS
Packing Method TR
Subcategory FF/Latches
Type JK Type
Termination SMD/SMT
Number of Terminations 14
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Series 74HC
Packaging Tape & Reel (TR)
Operating Temperature -55°C~125°C TA
Physical
Weight 129.387224mg
Number of Pins 14
Package / Case 14-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 6 Weeks
