CD40175BE
RoHS
/
Package 16-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Tube 4000B Obsolete Differential flip flop 5.33mm 3V 120ns @ 15V 50pF 14MHz
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8096
≥1 USD $0.8096
≥10 USD $0.71544
≥100 USD $0.67232
≥500 USD $0.54868
≥1000 USD $0.509626
≥3000 USD $0.433734
Inventory: 1191
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 7.62mm
Height Seated (Max) 5.33mm
Technical
Input Capacitance 5pF
Trigger Type Positive Edge
Max Propagation Delay @ V, Max CL 120ns @ 15V, 50pF
Number of Bits per Element 4
Output Polarity COMPLEMENTARY
Current - Output High, Low 6.8mA 6.8mA
Current - Quiescent (Iq) 4μA
Clock Frequency 14MHz
Supply Voltage-Min (Vsup) 3V
Number of Elements 1
Output Type Differential
Qualification Status COMMERCIAL
Function Master Reset
Supply Voltage 5V
Terminal Position DUAL
Voltage - Supply 3V~18V
Technology CMOS
Type D-Type
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Series 4000B
Packaging Tube
Operating Temperature -55°C~125°C TA
Physical
Surface Mount NO
Package / Case 16-DIP (0.300, 7.62mm)
Mounting Type Through Hole
