MM74HCT374WMX

ON Semiconductor
RoHS
RoHS RoHS compliant
Package 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description Tape & Reel (TR) 74HCT374 e3 74HCT flip flop 801mg 46ns @ 5V 150pF 30MHz 57ns
PDF
/
Buying Options
Total Price: USD $0.38
Unit Price: USD $0.3784
≥1 USD $0.3784
Inventory: 26071
Minimum: 1
-
+

Technical Details

Technical

Number of Output Lines 3
Clock Edge Trigger Type Positive Edge
Input Capacitance 10pF
Trigger Type Positive Edge
Max Propagation Delay @ V, Max CL 46ns @ 5V, 150pF
Max I(ol) 0.006 A
Current - Output High, Low 7.2mA 7.2mA
Current - Quiescent (Iq) 8μA
Logic Function D-Type, Flip-Flop
Family HCT
Turn On Delay Time 30 ns
Propagation Delay 57 ns
Clock Frequency 30MHz
Number of Bits 8
Number of Ports 2
Load Capacitance 50pF
Number of Circuits 8
Power Supplies 5V
Polarity Non-Inverting
Number of Elements 1
Operating Supply Voltage 5V
Output Type Tri-State, Non-Inverted
Function Standard
Base Part Number 74HCT374
Supply Voltage 5V
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology CMOS
Packing Method TAPE AND REEL
Subcategory FF/Latches
Terminal Finish Tin (Sn)
Type D-Type
ECCN Code EAR99
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series 74HCT
Published 2005
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C TA

Dimensions

Width 7.5mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free

Physical

Weight 801mg
Number of Pins 20
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Mount Surface Mount

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 2 days ago)
Factory Lead Time 4 Weeks
