MC100EP35DG
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Tube 100EP35 e3 100EP flip flop 4.9mm 3V 3GHz 0.575ns
PDF
/
Buying Options
Total Price: USD $4.83
Unit Price: USD $4.83265
≥1 USD $4.83265
≥10 USD $3.9653
≥100 USD $3.8418
≥500 USD $3.71735
≥1000 USD $3.59385
Inventory: 93
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 4 Weeks
Lifecycle Status LIFETIME (Last Updated: 1 month ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Number of Pins 8
Technical
Operating Temperature -40°C~85°C TA
Packaging Tube
Published 2000
Series 100EP
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Type JK Type
Terminal Finish Tin (Sn)
Additional Feature NECL MODE: VCC = 0V WITH VEE = -3V TO -5.5V
Subcategory FF/Latches
Packing Method RAIL
Technology ECL
Voltage - Supply -3V~-5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number 100EP35
Function Reset
Output Type Differential
Operating Supply Voltage 4.25V
Polarity Non-Inverting
Supply Voltage-Max (Vsup) 5.5V
Power Supplies -4.5V
Supply Voltage-Min (Vsup) 3V
Output Current 50mA
Number of Bits 2
Clock Frequency 3GHz
Propagation Delay 575 ps
Turn On Delay Time 410 ps
Logic Function Flip-Flop, JK-Type, NOR, OR
Halogen Free Halogen Free
Prop. Delay@Nom-Sup 0.575 ns
Trigger Type Positive Edge
High Level Output Current -50mA
Low Level Output Current 50mA
Number of Output Lines 1
Clock Edge Trigger Type Positive Edge
Max Frequency@Nom-Sup 3000000000Hz
Dimensions
Length 4.9mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
