N74F534D,602
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Logic - Flip Flops
Description
Not Qualified Standard D-Type TTL Flip Flop 0C~70C TA 86mA 50pF 4.5V~5.5V
PDF
/
Buying Options
Total Price: USD $0.28
Unit Price: USD $0.2816
≥1 USD $0.2816
Inventory: 1002
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.5mm
Height Seated (Max) 2.65mm
Technical
Propagation Delay (tpd) 7.5 ns
Trigger Type Positive Edge
Max Propagation Delay @ V, Max CL 7ns @ 5V, 50pF
Number of Bits per Element 8
Max I(ol) 0.024 A
Current - Output High, Low 3mA 24mA
Output Characteristics 3-STATE
Current - Quiescent (Iq) 86mA
Family F/FAST
Clock Frequency 165MHz
Number of Ports 2
Load Capacitance 50pF
Supply Voltage-Min (Vsup) 4.5V
Power Supplies 5V
Supply Voltage-Max (Vsup) 5.5V
Number of Elements 1
Output Type Tri-State, Inverted
Qualification Status Not Qualified
Function Standard
JESD-30 Code R-PDSO-G20
Base Part Number 74F534
Time@Peak Reflow Temperature-Max (s) 30
Reach Compliance Code unknown
Supply Voltage 5V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.5V~5.5V
Technology TTL
Subcategory FF/Latches
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
Type D-Type
Number of Terminations 20
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Series 74F
Published 2013
Packaging Tube
Operating Temperature 0°C~70°C TA
Physical
Surface Mount YES
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
