CMX649D3
RoHS
RoHS compliant
RoHS compliantPackage 20-SOIC (0.295, 7.50mm Width)
Category Integrated Circuits (ICs) / Interface - CODECs
Description
Surface Mount ROHS3Compliant GULL WING 2013 codec -40C~85C 12.76mm 3V 8b 16b
PDF
/
Buying Options
Total Price: USD $46.08
Unit Price: USD $46.082626
≥1 USD $46.082626
≥10 USD $43.474173
≥100 USD $41.01337
≥500 USD $38.691858
≥1000 USD $36.501752
Inventory: 6336
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 7.425mm
Length 12.76mm
Height Seated (Max) 2.67mm
Technical
Companding Law A/MU-LAW
Filter NO
Number of ADCs / DACs 1 / 1
Sigma Delta No
Resolution (Bits) 8 b, 16 b
Voltage - Supply, Digital 2.7V~5.5V
Voltage - Supply, Analog 2.7V~5.5V
Data Interface Serial
JESD-30 Code R-PDSO-G20
Pin Count 20
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 1.27mm
Supply Voltage 3V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
HTS Code 8542.39.00.01
Terminal Finish Matte Tin (Sn)
Type General Purpose
Number of Terminations 20
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2013
Operating Temperature -40°C~85°C
Physical
Surface Mount YES
Package / Case 20-SOIC (0.295, 7.50mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
